AB Nautilus 12 DLX
A perfect blend of thoughtful design, top-of-the-line features and elegant craftsmanship. Performance driven & beautifully crafted, our full-featured moulded-in deck Nautilus 12 DLX remains unparalleled in quality and style.
Our thoughtfully redesigned 12 DLX features the finest manoeuvrability and stylish finishing made to keep up with the adventure-seekers while providing comfort to those seeking relaxation. From the cushioned bow area to the convenient low helm station and its ergonomically positioned throttle, this handcrafted model, which delivers extra safety for children and pets, is specially designed for comfort and elegance.
Standard Features
Hand Laid Fibreglass Deep āVā Hull
Stringer System Laminated into Hull
Diamond Shape Non-skid Deck
Integrated Marine Grade Aluminium Fuel Tank
Plastic External Transom Plate
Aluminium Internal Transom Plate
Splash well, Draining
One All Integrated Deck with Bow Front & Lateral Closed Cell Cushions
Raised Single Rub Rail
Push Push Plastic Non-Corrosive 2 Stage Inflation Valves
Orca (CSM) Five Layer Coated Hypalon Fabric
Hand Pump
Maintenance Kit
Owner's Manual
Fully Upholstered Seating ā Spradling
Port Boat Entrance Step with Diamond Shape Non-Skid
Integrated Fibreglass Console with Lateral Seat & Cushion
Sporty Console Look Design with SS Hand Rail & Plexiglass Windshield
Height Adjustable Steering Wheel
Removable Lateral Seat
Moulded-In Stern Seat & Cushion with Armrest & Large Storage
1 SS Cup Holder
4 Deck Drains
Hull Drain with Plug
Bow Locker/Seat
Bow Hatch Cushion
Built-In Cooler with Cushion
Console Front Access Lid
Bow Step with Fold Down Stainless Steel Cleat & Running Lights
360Ā° White Anchor Light Pole
Integrated Stainless Steel Bow Port & Starboard Hand Rails
Lateral Fold Down Stainless Steel Cleat
3 Stainless Steel Davit Lifting Points
Stainless Steel Console Grab Handle
Stainless Steel Tie Down & Towing Rings
Stainless Steel Bow Eye
Stainless Steel Transom Tie Down & Towing Rings
Deluxe Carbon Fiber Style Panel
4 Waterproof Rocker Switches with Circuit Breakers
Battery Box
Battery Switch
Fuel and Water Separator Filter
Fuel Sending Unit
Automatic Bilge Pump 500 GPH
Mechanical Steering System
Stainless Steel Steering Wheel
Complete Tin Wiring & (Head) Heat Shrink Seal Terminals
3 Layers Reinforced Seams
Specifications
Overall Length - 12' / 3.66m
Overall Beam - 6' / 1.82m
Inside Length - 9'2" / 2.79m
Inside Beam - 2'10" / 0.86m
Tube Diameter - 18" / 0.46m
Number of Chambers - 3
Person Capacity - 5
Weight - 515lb / 234kg
Recommended HP - 40HP
Maximum HP - 50HP
Shaft Length - 20" / 50.8cm
Fuel Built-In Tanks - 13 gal / 49 L
RDC Design Category - C
